JFX Technologies jual Dahua ASC3202B Access Controller dengan harga terbaik di Jakarta, Indonesia. Dapatkan harga Dahua ASC3202B Access Controller dengan menghubungi sales@jfxtechnologies.com. Kami juga jual produk Access Control lainnya baik dari Dahua ataupun merk lain, klik disini untuk pilihan produk Access Control lainnya. Berikut penjelasan singkat mengenai Dahua ASC3202B Access Controller atau untuk informasi datasheet bisa download disini

Dahua ASC3202B Access Controller

Dahua ASC3202B Access Controller :

  • Bulit-in Web server, features main and sub control modes.
  • The main control mode offers access control Platform functions, can connect with and manage up to 19 sub controllers. The sub-control modes can be added to multiple platforms.
  • Supports 1000 users, 3000 fingerprints, and 300,000 records.
  • Accesses card readers through Wiegand and RS-485 protocols.
  • Supports TCP and IP connection, and standard PoE.
  • Supplies power to the lock through its 12 VDC output power supply, which has a maximum output current of 1000 mA.
  • Supports configuring the hardware I/O port and exporting configuration diagrams.
  • Retains stored data even while powered off.

System

  • Main Processor Embedded processor
  • Internet Protocol P2P; IPv4; DNS; DDNS; TCP; UDP
  • Interoperability ONVIF; CGI
  • SDK and API Yes

Basic

  • Product Type Controller
  • Buzzer Yes
  • Casing Material PC + ABS

Function

  • Unlock Mode Card; remote; password; fingerprint; combination unlock
  • Period List 128 periods
  • Holiday Period 128 periods
  • Network Update Yes
  • Blocklist/Allowlist Yes
  • Peripheral Card Reader Supports 2 × RS-485 card readers; 2 × Wiegand card readers
  • Multi-user Authentication Yes (Use with platform)
  • Real-time Monitoring Yes
  • Multi-factor Authentication Yes
  • Web Configuration Yes

User

  • User (Card) Type General users, patrol users, blocklist users, VIP users, guest users, custom user 1, custom user 2, and other users

Capacity

  • User Capacity 1000
  • Fingerprint Capacity 3000
  • Card Capacity 5000
  • Record Capacity 300,000

Port

  • RS-485 3
  • Wiegand 2 × input
  • Network Port 1 × RJ-45 10/100 Mbps Ethernet port
  • Alarm Input 2 (digital quantity)
  • Alarm Output 2 (digital quantity)
  • Alarm Linkage Yes
  • Exit Button 2
  • Door Status Detection 2
  • Lock Control 2

Alarm

  • Tamper Alarm Yes
  • Duress Alarm Yes
  • Door Sensor Timeout Yes
  • Intrusion Yes
  • Illegal Card Exceeding Threshold Yes
  • Duress Fingerprint Yes

Selain jual Dahua ASC3202B Access Controller, JFX Technologies juga menerima jasa instalasi dan maintenance Access Control dengan harga bersaing. Kami tidak sekedar jual Dahua ASC3202B Access Controller, tetapi juga memberikan jaminan atas barang yang anda beli.
